DNA-RNA Hybrid Antibody [S9.6]

In Stock
Best Seller
Catalog Number Formulation Size Price
MSM1-2006-P0
Purified Ab with BSA and Azide at 200ug/ml
20ug
$229.00
MSM1-2006-P1
Purified Ab with BSA and Azide at 200ug/ml
100ug
$519.00
MSM1-2006-P1ABX
Purified Ab WITHOUT BSA and Azide at 1.0mg/ml
100ug
$519.00
Flat Rate Domestic: $60 | Orders outside the US - Contact Us for Order Information | Ships next business day

Applications & Dilutions

Applications Tested Dillution Protocol Note
Flow Cytometry (Flow)
1-2ug/million cells
We did not test in flow cytometry in-house, information comes from publications
Immunofluorescence (IF)
1-3ug/ml
We did not test in Immunofluorescence in-house, information comes from publications

Summary

We have not tested this antibody in-house in Immunofluorescence, CHIP, Immunocytochemistry, Immunoprecipitation or Flow Cytometry. All application recommendations come from publications using this clone.

DNA-RNA hybrids are a natural occurrence within eukaryotic cells and their level are high at sites of high transcriptional activity. They are non-canonical nucleic acid structures with transcriptional regulatory functions. Their presence is reported to predispose a locus to chromosomal breakage. A locus forming an DNA:RNA creates a double-stranded A/B intermediate conformation, with a second target for single-stranded nucleic acid binding proteins on the complementary, displaced DNA strand. They are shown to be resistant to the activity of DNA methyltransferases. The formation of DNA:RNA hybrids has been associated with a number of neurological diseases. Mutations in the DNA:RNA helicase senataxin (SETX) are implicated in the dominant juvenile form of amyotrophic lateral sclerosis type 4 and a recessive form of ataxia oculomotor apraxia type 2.

Clone S9.6 bound the DNA-RNA heteropolymer and poly(I)-poly(dC) equally, but 100-fold higher levels of poly(A)-poly(dT) were required to achieve a similar degree of binding. Single-stranded DNA, double-stranded DNA and RNA, and ribosomal RNA were not bound by clone S9.6 (Boguslawski, S.J., et al. (1986). J. Immunol Methods. 89(1):123-130).

Product Properties & Targets

Antibody Type
Host
Mouse
Species Reactivity
Isotype / Light Chain
IgG2a / Kappa
Cellular Localization
Nucleus
Positive Control
All. Target DNA-RNA heteroduplex (R loop) structure is not sequence-specific or species-specific.
Immunogen
DNA-RNA heteropolymer duplex prepared by transcription of phi X174 single-stranded DNA with DNA-dependent RNA polymerase
Alternate Names
DNA-RNA Hybrid, DNA-RNA Duplex; DNA/RNA Duplex; DNA:RNA Duplex; DNA-RNA Hybrid; DNA/RNA Hybrid; DNA:RNA Hybrid; RNA-DNA Duplex; RNA/DNA Duplex; RNA:DNA Duplex; RNA-DNA Hybrid; RNA/DNA Hybrid; RNA:DNA Hybrid

Database Links

Entrez Gene ID
SwissProt

Additional Information

Clone
S9.6
Chromosome Location
Not Applicable
Mol. Weight of Antigen
Not Known

Key References

  • Bou-Nader C, Bothra A, Garboczi DN, Leppla SH, Zhang J. Structural basis of R-loop recognition by the S9.6 monoclonal antibody. Nat Commun. 2022 Mar 28;13(1):1641. doi: 10.1038/s41467-022-29187-7. PMID: 35347133; PMCID: PMC8960830.
  • Phillips DD, Garboczi DN, Singh K, Hu Z, Leppla SH, Leysath CE. The sub-nanomolar binding of DNA-RNA hybrids by the single-chain Fv fragment of antibody S9.6. J Mol Recognit. 2013 Aug;26(8):376-81.
  • Hu Z, Zhang A, Storz G, Gottesman S, Leppla SH. An antibody-based microarray assay for small RNA detection. Nucleic Acids Res. 2006 Apr 13;34(7):e52.

Storage & Stability

Antibody with azide - store at 2 to 8°C. Antibody without azide - store at -20 to -80°C.Antibody is stable for 24 months. Non-hazardous. No MSDS required.

Limitations

This antibody is available for research use only and is not approved for use in diagnosis.

Supplied as

200ug/ml of Ab purified from Bioreactor Concentrate. Prepared in 10mM PBS with 0.05% BSA & 0.05% azide. Also available WITHOUT BSA & azide at 1.0mg/ml.

Warranty

There are no warranties, expressed or implied, which extend beyond this description. Company is not liable for any personal injury or economic loss resulting from this product.
